Nauticam Wet Wide Lens 1B (WWL-1B) incl. float collar

Nauticam Wet Wide Lens 1B (WWL-1B) incl. float collar

1.369,00 EUR

(incl. VAT)

The next generation of WWL-1 is available! The Nauticam WWL-1B features the same amazingly sharp optics as the WWL-1, but it now includes an integrated aluminum buoyancy collar to make it nearly neutral in water. The WWL-1 and now WWL-1B are still the highest quality wet-changeable underwater wide-angle conversion optics ever made, featuring unmatched contrast, overall sharpness, corner sharpness, and clarity. The design is truly full zoom through, allowing zoom to to be used as a tool for framing, and removable in water for close-up and macro shots.

Product no.: 83202
Stock status: In stock

130° of glorious wide angle coverage is waiting for you...even a bit wider if your camera system allows it! This is a field of view that sits between the popular full frame fisheye lenses (180° diagonal) and ultra wide rectilinear zooms (approximately 110°). This coverage angle was targeted from the very beginning as an ideal coverage angle for a wide variety of underwater imaging scenarios. Big animals, close focus wide angle shots of reef dwelling creatures, and even mid-range fish portraits are all within the range of WWL-1B.

The cutting edge optical design employed in the Nauticam WWL-1B results in extremely high overall sharpness, contrast, and edge sharpness. The design is optimized for the high resolution sensors of today, as well as the even higher resolutions sensors of tomorrow.

The ability to focus close is key, and WWL-1B does amazingly well. With all compatible systems at wide angle the lens is able to focus on the front of its dome lens element, maximizing the impact of even small subjects. Amazingly, with the Panasonic 14-42 Power Zoom, the lens is still able to focus on the front of the dome port when zoomed to full telephoto! The best macro images will always be obtained by removing WWL-1B and mounting a macro converter (such as CMC-1 or CMC-2), but in situations where that is difficult close-up shots can still be obtained without removing the wide angle conversion lens.



Dimensions: 156mm x 97mm
Weight (air / underwater):    1.35kg / 0.12kg
Body Construction: Hard-anodized aluminum alloy
Lens Construction: 6 elements in 5 groups
Lens Coating: Inside anti-reflective coating
Maximum Field of View (underwater): 130° for 28mm equivalent lens
Focal Range: Front element to infinity
Mount System: Bayonet Mount II
Depth Rating: 150m



WWL-1B (83202)
Hard lens cap for WWL-1B
Rear lens cap for WWL-1B
Padded carrying bag
Lens cloth


- 83250 M67 to Bayonet Converter II
- 83251 M77 to Bayonet Converter II

For optics storage on standard arms:

- 83252 Single Bayonet Holder II for Arms
- 83253 Double Bayonet Holder II for Arms
- 83254 Single Bayonet Holder II for Inon Arms

For optics storage on Nauticam Carbon Fiber Float Arms:

- 72234 Double Bayonet Holder II for 70mm Carbon Fiber Float Arms
- 72233 Single Bayonet Holder II for 70mm Carbon Fiber Float Arms
- 72244 Double Bayonet Holder II for 90mm Carbon Fiber Float Arms
- 72243 Single Bayonet Holder II for 90mm Carbon Fiber Float Arms
