NIKON D850 HOUSING 200DL

Features

• New Dry Lock (DL) port system
• New ports are lighter, more adaptable, and can accommodate large diameter lenses
• Engage the zoom lenses and select lens focus rings simple and effective with the new gearing system.
• Vacuum system
• Upgraded shutter and AF-ON levers
• Lighter than a typical FL counterpart
• New hard anodized aluminum base with quick release handle
• Redesigned push buttons to reduce weight and resist salt buildup
• New and strong white ABS-PC blend front for improved contrast and visibility while keeping the camera cooler in the sun.
• 1/4-20 threaded mounting can be used to attach lightweight accessories like a focus light or a GoPro Camera

Fiber Optic

An external strobe needs to be connected by electrical sync cord. Fiber optic only strobes are not compatible.

Compatibility

This housing cannot accommodate add-on grips, battery grips, eyepieces, LCD covers or other accessories.

Specifications

60m depth rating

Compatible with DL system lens ports

Controls are provided for all important camera controls; Controls are not provided for Release mode dial, Release mode dial lock release, Diopter adjustment control, Focus mode selector, PV button, Fn1 button, Eyepiece shutter lever, Sub selector, Focus selector lock

1/4-20 thread base mounts with 3.5" spacing

Near neutral buoyancy in fresh water

Actual buoyancy varies depending on choice of lens and port

4.9 lb (2.2 kg)

9.1 x 7 x 6.5" (231 x 178 x 165 mm)

Vacuum valve included (pump sold separately)

Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provides automatic exposure with compatible Ikelite DS strobes

ABS-PC construction is fundamentally corrosion-resistant

Made in the USA; Individually inspected for fit and water pressure tested to depth

2 year limited warranty

In the Box

Housing

Rear o-ring # 0132.61 (installed)

Front o-ring # 0132.45 (installed)

Zoom Gear Retainer # 75900 (installed)

Port Hole Cover # 0200.92 (installed)

Waterproof Bulkhead Cap # 9104.7 (installed)

Base with Left-Hand Quick Release Handle # 4077.67 (installed)

Tool for Zoom Gear Retainer # 0945.06

.050" Hex Key # 0945.11

1/16" Hex Key # 0945.16

Silicone Lubricant  1cc tube

Optional Accessories

Spare Rear O-Ring # 0132.61  Carry a back-up in case original seal becomes damaged.

Spare Front O-Ring # 0132.45  Carry a back-up in case original seal becomes damaged.

Vacuum Pump with Gauge # 47011  Pressurize the housing to check for leaks prior to entering the water.

Right-Hand Quick Release Handle # 4077.02  Makes a double tray for easier handling and a second attachment point for strobes or lights.

Trigger Extension # 4077.95  Recommended if using the Right-Hand Quick Release Handle. Brings shutter and/or AF-ON lever out to handle for more comfortable use.

DL1 DS Link TTL Converter # 46054  Fast, accurate, automatic TTL strobe exposure when used together with compatible Ikelite DS strobes.

45º Magnified Viewfinder (Type 1) # 6891.1  Brighter, larger, and more ergonomic positioning when shooting under water. Rotates for landscape or portrait shots.
